My Projects

Kategorie: 3 Axis CNC Platform

AC Table completed

Posted on August 22, 2018August 22, 2018 adminLeave a commentPosted in 3 Axis CNC Platform, 5 Axis CNC

the AC Table (4th and 5th Rotary axis) is completed. Check it out

New Z Axis in Action

Posted on Februar 21, 2018Februar 21, 2018 adminLeave a commentPosted in 3 Axis CNC Platform

PA6 Milling

Posted on Juni 9, 2017 adminLeave a commentPosted in 3 Axis CNC Platform

New CNC Platform completed

Posted on April 19, 2017 adminLeave a commentPosted in 3 Axis CNC Platform

Complete new version built and tested.  Stable and rigid, good for milling alu. pretty big working area (700x550x80). Raspberry based electronics, NEMA 23 Stepper.

The real thing in action

Posted on Mai 17, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

See the new CNC Platform version in Action:

Precision of the new CNC Platform

Posted on Mai 17, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

Here you can see the precision of the new CNC Platform. In this test cycle, the machine is moving 3x1mm forward and then 3x1mm back. The precision is in the range of 0.02mm

New CNC platform version completed

Posted on Mai 1, 2016Mai 1, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

Details

CNC Platform „the Real Thing“

Posted on März 17, 2016März 17, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

… erste Version steht mal, hier einige Impressionen:

3D PDF now available

Posted on März 7, 2016März 17, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

AnlageKomplett 3D PDF

Erster Gehversuch …

Posted on März 6, 2016 adminLeave a commentPosted in 3 Axis CNC Platform

Die CNC Plattform nimmt Form an: erste Tests waren erfolgreich. Hier eine erstes Video vom „Real Thing“.
